| Analog Video Input | 4 Channels |
| HDTVI Input | 3 MP, 1080p30, 1080p@25 fps, 720p@60 fps, 720p@50 fps, 720p@30 fps, 720p@25 fps |
| AHD Input | 4 MP, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps |
| HDCVI Input | 4 MP, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps |
| CVBS Input | PAL/NTSC |
| IP Video Input | 1-ch (up to 5-ch) |
| IP Video Support | Up to 4MP |
| Audio input | 1-Ch RCA |
| Video Compression | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Audio Compression | G711.u |
| CVBS Output | 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 x 576, NTSC: 704 x 480 |
| HDMI/VGA Output | 1-ch, 1920 ? 1080/60Hz, 1280 ? 1024/60Hz, 1280 ? 720/60Hz, 1024 ? 768/60Hz, HDMI/VGA simultaneous output |
| Encoding Resolution | When 1080p lite mode not enabled: For 4 MP stream access: 4 MP lite@15 fps; 1080p lite/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N) For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15 fps For 1080p stream access: 1080p/720p@15 fps; VGA/WD1/ |
| Video bit Rate | 32 Kbps to 6 Mbps |
| Audio Output | 1-Ch RCA |
| Audio bit Rate | 64 Kbps |
| Dual Stream | Supports |
| Stream Type | Video, Video & Audio |
| 1Synchronous Playback | 4 Channels |
| Remote Connections | 32 |
| Network Protocols | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF |
| SATA | 1 HDD |
| HDD | Up to 10 TB |
| Network Interface | 1 RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface |
| USB Interface | 1 x USB 2.0 |
| Power Supply | 12 VDC |
| Video Input Channels | 4 Ch |
