| Sensor | 1/2.8" CMOS |
| Max. Image Resolution | 1920 x 1080 |
| Minimum Illumination | 0.025 lux@F2.0 (Color, 30 IRE) 0.0025 lux@F2.0 (B/W, 30 IRE) 0 lux (Illuminator on |
| Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Lens | 2.8mm |
| Microphone | Built-in |
| Day& Night | Auto (ICR)/Color/B/W |
| Wide Dynamic Range | DWDR |
| Video Compression | H.264B; H.264; H.264H; H.265 |
| Video bit Rate | H264: 24 kbps–4096 kbps H265: 9 kbps–4096 kbps |
| Ingress Protection IP | IP67 |
| Frame Rate | Main stream: 1920 ? 1080 (1–25/30 fps) Sub stream: 640 ? 480@(1–25 fps) 640 ? 480@(1–30 fps) |
| Network Protocols | IPv4; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; DHCP; DNS; NTP; Multicast; RTMP |
| Working Temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Power Consumption | Basic: 2 W (12 VDC) Max. (H.265+IR intensity): 4.1 W (12 VDC) |
| Dimensions (W x D x H) | 166.2 mm x 70.0 mm x 128.6 mm (6.53" x 2.76" x 5.06") |
| Weight | 477.9 g (1.05 lb) |
| Horizontal Resolution | 1920 |
| S/N Ratio | >56 dB |
| Recognition | Face Detection |
| Power Supply | 12 VDC |
| Bracket 1 | PFA152-E Pole Mount |
