| Specifications | |
| Standards | IEEE 802.3 |
| IEEE 802.3u | |
| IEEE 802.3x | |
| IEEE 802.3ab | |
| IEEE 802.3az | |
| Device Interface | 5 x Gigabit ports |
| LED indicators | |
| Data Transfer Rate | Ethernet: 10Mbps (half duplex), 20Mbps (full duplex) |
| Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex) | |
| Gigabit: 2000Mbps (full duplex) | |
| Performance | Data RAM buffer: 128KB |
| Switch fabric: 10Gbps | |
| MAC address table: 2K | |
| Forwarding rate: 7.44Mpps (64-byte packet size) | |
| Jumbo frame: 9KB | |
| Special Features | GREENnet energy saving technology |
| Metal enclosure | |
| Wall Mountable | |
| Power | Input: 100 – 240V AC, 50/60Hz, 0.15A |
| Output: 5V DC, 1A external power adapter | |
| Max. consumption: 2.75W | |
| Fan/Acoustics | Fanless design |
| MTBF | 2,152,216 Hours |
| Operating Temperature | 0° – 40° C (32° – 104° F) |
| Operating Humidity | Max. 90% non-condensing |
| Dimensions | 116 x 70 x 25mm (4.6 x 2.8 x 1 in.) |
| Weight | 192g (6.8 oz.) |
| Certifications | CE |
| FCC | |
